Lithium titanate

Li₄Ti₅O₁₂

MFCD11656084

329767159

NA.23

We are committed to bringing you Greener Alternative Products, which adhere to one or more of The 12 Principles of Greener Chemistry. This product has been enhanced for energy efficiency. Find details here.
Lithium titanate (LTO) is a class of electrode material that can be used in the fabrication of lithium-ion batteries. Lithium-ion batteries consist of anode, cathode, and electrolyte with a charge-discharge cycle. These materials enable the formation of greener and sustainable batteries for electrical energy storage.

Lithium titanate (LTO) spinel electrode sheet can be used as an anode material, which shows an ion conductivity of 10⁻³ Scm⁻¹ at room temperature. It can also be used as an alternative to conventional graphite materials. It can further be used in the fabrication of high-performance lithium-ion batteries for electric vehicles (EVs).

Crystal Structure: Spinel, cubic, Fd-3m

Operating Condiditons:

• Recommended maximum charge voltage: 3.0 V vs Li/Li⁺
• Recommended maximum charge current: 5 C
• Recommended cut-off voltage for discharge: 1.0 V vs Li/Li⁺
• Recommended maximum discharge current: 10 C

100

≥98%

Design for Energy Efficiency
Learn more about the Principles of Green Chemistry.

≥80% loading

1.5 V, Li/Li⁺

5 in. × 10 in.

25-50 μm

150 mAh/g(minimum)
160 mAh/g(nominal at 0.1C)

>1000 ℃

battery manufacturing

Enabling

[Li+].[Li+].[Li+].[Li+].[O-][Ti](=O)O[Ti](O[Ti]([O-])=O)(O[Ti]([O-])=O)O[Ti]([O-])=O

1S/4Li.12O.5Ti/q4*+1;;;;;;;;;4*-1;;;;;

BNQVSKURWGZJMY-UHFFFAOYSA-N

1 ea in glass bottle

11 - Combustible Solids

WGK 3
