Fluoropore Membrane Filter

32031602

NB.24

Our Fluoropore^® membrane is a hydrophobic, polytetrafluoroethylene (PTFE) polymer membrane bonded to a high density polyethylene support to improve the handling characteristics of the filter for normal applications. Fluoropore membranes provide broad chemical compatibility, high flow rates and consistency. (Please note that catalogue numbers containing "FHUP" are unlaminated, or produced without a backing.)

Our Omnipore membrane is a hydrophilic PTFE membrane that is compatible with virually all solvents, acids, and alkaline solutions.

Features & Benefits:
- Biologically and chemically inert
- High porosity yields high flow rates
- Hydrophobic and hydrophilic PTFE varieties available for filtration of aqueous and organic-based samples

Applications:
- Fluoropore Membrane: Clarifying Acids, Bases and Solvents; Air Monitoring; Filtering and Venting Gases; UV Spectroscopy

- Omnipore Membrane: Filtration of Aqueous Solutions, Clarifying Acids and Alkaline Solution
Filter Code: FALP
Filter Type: 表面滤膜

1.0 µm pore size, hydrophobic PTFE, 13 mm membrane
Product Filters Out: Diborane

Fluoropore is a registered trademark of Merck KGaA, Darmstadt, Germany

PTFE membrane
plain filter
white filter

in accordance with NIOSH 6006

hydrophobic

Fluoropore^®
Millipore

100 mL/min-cm² water flow rate
130 ℃ max. temp.
16 L/min-cm² air flow rate

13 mm

150 μm

0.5%

Fluoropore^®

1.0 μm pore size
85 % porosity

≥0.5 bar, air with methanol at 23 ℃

ambient
