带 PTFE/丁基橡胶隔垫的钳口密封盖 (Pharma-Fix)
Crimp seal with PTFE/butyl septum (Pharma-Fix)
| 产品编号： | 3447625 |
| 规格： | aluminum seal (with 10 mm center hole), PTFE-faced butyl septum, diam. × thickness 20 mm × 3.0 mm, pkg of 100 ea |
| 包装规格： | 100 EA |
| 产品类别： | 进口试剂 |
| 品牌： | Supelco |
| 优惠价： | 立即咨询 |
产品别名
带 PTFE/丁基橡胶隔垫的钳口密封盖 (Pharma-Fix)
Crimp seal with PTFE/butyl septum (Pharma-Fix)
基本信息
| NACRES | NB.11 |
| Application【应用】 | Crimp seal with PTFE/butyl septum (Pharma-Fix) may be used to seal standard residual solvents for the determination of residual solvents in drug substances using headspace gas-chromatography coupled with flame ionization detector (HS-GC-FID). PTFE-faced butyl septum was used in sealing headspace vials to analyse the sampling efficiency and breakthrough of methyl bromide on activated charcoal using GC. It was also used for sealing water samples during headspace analysis with GC-FID, in a study which demonstrates cross-validation of methods used for methyl-tert-butyl ether (MTBE) analysis. |
产品性质
| material【物料】 | PTFE-faced butyl septum aluminum seal (with 10 mm center hole) |
| hardness【硬度】 | 50 (Durometer: shore A) |
| packaging【包装】 | pkg of 100 ea |
| O.D.【外径】 | 20 mm |
| diam. × thickness【直径× 厚度】 | 20 mm × 3.0 mm |
| fitting【配件】 | thread for 20 mm |
