多层碳纳米管

NA.23

Multi-walled carbon nanotube core surrounded by a fused carbon shell, the remainder being multi-layer polygonal carbon nanoparticles and amorphous and graphitic carbon nanoparticles.It contains approximately 5-20 graphitic layers. Carbon nanotubes produced by arc discharge technique contain very low impurity and possesses very high crystallinity. 4

Bundles of MWNTs were trapped and manipulated to form nanotube ropes using optical tweezer. MWNTs were calcined and sonicated to form carbon nanoribbons. The nanoribbons were used to fabricate array of 98 source and drain electrodes on a 300 nm SiO₂/p++Si substrates.2 A MWNT probe was fabricated on Si cantilevers.
Carbon nanotube, multi-walled (MWNT) belongs to the class of carbonaceous materials with excellent physiochemical, thermo-mechanical and electrochemical properties. This material can be used in a variety of sustainable energy applications such as solar cells, photocatalysis, biosensor, gas sensor, supercapacitor and as a filler that acts as a reinforcement to improve the mechanical property of composites.

大约 5-20 层石墨。含大约 10-40% 的纳米管，其余的为多层多边形碳纳米粒子以及无定形和石墨碳纳米粒子。

由电弧法生产

We are committed to bringing you Greener Alternative Products, which adhere to one or more of The 12 Principles of Greener Chemistry. This product has been enhanced for energy efficiency. Find details here.

100

20-30% MWCNT basis

powder

carbon content, >99% TGA

Design for Energy Efficiency
Learn more about the Principles of Green Chemistry.

7-12 nm × 0.5-10 μm

−270 mesh
<53 μm

3652-3697 ℃ (lit.)

~2.1 g/mL at 25 ℃ (lit.)

Enabling

500 mg in glass insert
1, 5 g in glass bottle

11 - Combustible Solids

WGK 3

dust mask type N95 (US), Eyeshields, Gloves
