Lithium nickel manganese cobalt oxide
| 产品编号： | 3106037 |
| 规格： | electrode sheet, aluminum substrate, size 5 in. × 10 in. |
| 包装规格： | 1 EA |
| 产品类别： | 进口试剂 |
| 品牌： | Sigma-Aldrich |
| 优惠价： | 立即咨询 |
产品别名
Lithium nickel manganese cobalt oxide
NMC
结构式
基本信息
| Linear Formula【线性分子式】 | LiNi0.33Mn0.33Co0.33O2 |
| NACRES | NA.23 |
| General description【一般描述】 | Lithium nickel manganese cobalt oxide (NMC) is a class of electrode material that can be used in the fabrication of lithium-ion batteries. Lithium-ion batteries consist of anode, cathode, and electrolyte with a charge-discharge cycle. These materials enable the formation of greener and sustainable batteries for electrical energy storage. We are committed to bringing you Greener Alternative Products, which adhere to one or more of The 12 Principles of Greener Chemistry. This product has been enhanced for energy efficiency. Find details here. |
| Application【应用】 | NMC electrode sheet has a layered structure and can be used as an active cathode material. It can further be used in combination with single electrolyte interphase (SEI) for the fabrication of lithium-ion batteries. |
| Other Notes【其他说明】 | Crystal Structure: Rhombohedral Operating Conditions:
|
产品性质
| Quality Level【质量水平】 | 100 |
| greener alternative product characteristics【环保替代产品特性】 | Design for Energy Efficiency Learn more about the Principles of Green Chemistry. |
| extent of labeling【标记范围】 | ≥80% loading |
| Nominal Voltage【标称电压】 | 3.5 V, Li/Li+ |
| size【尺寸】 | 5 in. × 10 in. |
| thickness【厚度】 | 25-50 μm |
| capacity【容量】 | 210 mAh/g(minimum) |
| mp | >1000 ℃ |
| application(s) | battery manufacturing |
| greener alternative category【环保替代产品分类】 | Enabling |
| packaging【包装】 | 1 ea in glass bottle |
安全信息
| Pictograms【象形图】 | GHS07,GHS08 |
| Signal word【警示用语：】 | Warning |
| Hazard Statements | H317 - H351 |
| Precautionary Statements | P201 - P202 - P261 - P280 - P302 + P352 - P308 + P313 |
| Hazard Classifications【危险分类】 | Carc. 2 - Skin Sens. 1 |
| Storage Class Code【储存分类代码】 | 11 - Combustible Solids |
| WGK | WGK 3 |
